Unexpected Row Returned in RIGHT JOIN Query Due to Automatic Index Optimization

Join Evaluation Anomaly in RIGHT JOIN with WHERE Clause Filtering

Issue Overview: RIGHT JOIN and WHERE Clause Interaction Producing Contradictory Results

The core issue arises from a SQLite query combining multiple RIGHT JOIN and LEFT JOIN operations with a WHERE clause condition that evaluates to NULL but unexpectedly returns a row. This occurs despite the WHERE clause appearing to filter out all rows. The contradiction manifests when two similar queries return logically inconsistent results:

1. A SELECT statement with RIGHT JOINs and a WHERE clause returns one row
2. A similar SELECT checking the truth value of the WHERE condition returns false (0)

Key Components of the Anomaly:

• Table Structure: Four empty tables (t0,t1,t2,t3) except t0 contains ‘x’ and t1 contains ‘y’

• Query 1:

  SELECT * FROM t2
  LEFT OUTER JOIN t3
  RIGHT OUTER JOIN t1
  RIGHT OUTER JOIN t0
  WHERE (t3.c0=t2.c0)


  Returns ||y|x (single row)

• Query 2:

  SELECT (t3.c0=t2.c0) IS TRUE
  FROM t2
  LEFT OUTER JOIN t3
  RIGHT OUTER JOIN t1
  RIGHT OUTER JOIN t0


  Returns 0 (false)

Fundamental Conflict:
The WHERE clause in Query 1 should eliminate all rows because t3.c0=t2.c0 evaluates to NULL (since both columns contain NULL from empty tables t2/t3). In SQLite, NULL in WHERE clauses is treated as false, yet Query 1 returns a row. Query 2 explicitly shows the condition evaluates to false, proving the WHERE clause should have filtered out the row.

Critical Observations:

• All joins except t0 are between empty tables
• RIGHT JOIN t0 forces inclusion of t0’s ‘x’ value
• Automatic index optimizations alter NULL handling logic
• SQLite 3.39.0’s RIGHT JOIN implementation interacts unexpectedly with WHERE clauses

Join Execution Context:
SQLite processes joins left-to-right with operator precedence influencing evaluation order. The chained RIGHT JOINs create a specific NULL propagation pattern:

((t2 LEFT JOIN t3) RIGHT JOIN t1) RIGHT JOIN t0

This structure preserves all rows from t0 (rightmost table), then t1, with t2/t3 contributing NULLs. The automatic index optimization (similar to hash joins) attempts to accelerate the WHERE clause evaluation but misapplies filtering rules when RIGHT JOINs are present.

Root Causes: Automatic Index Optimization Failure with RIGHT JOIN Semantics

The anomaly stems from SQLite’s query optimizer making incorrect assumptions about when automatic indexes can be safely used with RIGHT JOINs. Three interrelated factors create this failure mode:

1. Automatic Index Eligibility Rules for JOIN Clauses

• Automatic indexes (hash joins) are generated when WHERE clause terms reference columns from joined tables
• LEFT JOIN traditionally allows automatic indexes to use WHERE terms for index-driven table scans
• RIGHT JOIN changes NULL generation rules: Preserved tables (right side) require different NULL-check handling
• Pre-3.39.0 fix: Optimizer incorrectly applied LEFT JOIN index rules to RIGHT JOIN contexts

2. NULL Comparison Semantics in WHERE vs SELECT

• t3.c0=t2.c0 evaluates to NULL (both NULL) but WHERE treats NULL as false
• Automatic index optimization bypasses standard NULL evaluation when RIGHT JOINs alter table preservation order
• Index-driven query execution skips row elimination for NULL comparisons under specific join combinations

3. RIGHT JOIN Implementation Nuances

• SQLite historically simulated RIGHT JOIN via LEFT JOIN with reversed tables
• Native RIGHT JOIN support (post-3.39.0 experimental) introduces new optimization pathways
• Automatic index compatibility checks fail to account for RIGHT JOIN’s reversed table preservation

Execution Plan Breakdown (Pre-Fix):

1. t0 RIGHT JOIN t1 preserves all t0 rows, appending t1 columns (t1 has ‘y’)
2. RIGHT JOIN t2 preserves previous result (t2 empty → NULL columns)
3. LEFT JOIN t3 adds NULL columns from t3
4. Automatic index attempts to apply t3.c0=t2.c0 during join processing
5. Optimization incorrectly allows index use despite RIGHT JOIN context
6. WHERE clause filtering occurs before NULL comparison evaluation completes

Data Flow Corruption:

• Automatic index assumes t2/t3 columns are non-NULL for indexable comparisons
• RIGHT JOIN guarantees NULLs from t2/t3, making index-based comparisons invalid
• Query executor returns unfiltered row due to optimization-induced evaluation order change

Resolution Strategy: Query Restructuring and Version-Specific Fixes

Step 1: Verify SQLite Version and Configuration

• Run sqlite3 --version to confirm installation ≥3.39.0 with commit cab9b4cc
• Check RIGHT JOIN support: PRAGMA compile_options; should list ENABLE_RIGHT_JOIN
• Recompile from source with check-in 342c501f53252334 if needed

Step 2: Query Modification for Pre-Fix Environments

• Alternative 1: Avoid RIGHT JOIN syntax
  Rewrite using LEFT JOINs with reversed tables:

  SELECT * FROM t0
  LEFT JOIN (t1 LEFT JOIN (t2 LEFT JOIN t3 ON t3.c0=t2.c0))
  WHERE t0.rowid IS NOT NULL


• Alternative 2: Explicit NULL handling
  Force WHERE clause to account for potential NULLs:

  SELECT * FROM t2
  LEFT JOIN t3
  RIGHT JOIN t1
  RIGHT JOIN t0
  WHERE (t3.c0=t2.c0) IS TRUE -- Exclude NULL results


Step 3: Index Optimization Control

• Disable automatic indexes temporarily:

  PRAGMA automatic_index=OFF;


  Run original query – if it returns 0 rows, confirms optimization issue

Step 4: Upgrade and Regression Testing

• Apply official fix from SQLite 3.39.0+
• Validate with test case:

  CREATE TABLE t2(c0 INTEGER);
  CREATE TABLE t3(c0 INTEGER);
  EXPLAIN QUERY PLAN
  SELECT * FROM t2 LEFT JOIN t3 RIGHT JOIN t1 RIGHT JOIN t0
  WHERE t3.c0=t2.c0;


  Post-fix execution plan should show:

  SCAN t0
  SCAN t1
  SCAN t2
  SCAN t3


  Without automatic index usage on WHERE clause

Step 5: Query Planner Analysis

• Use EXPLAIN and EXPLAIN QUERY PLAN to inspect:
  • Automatic index creation attempts
  • Join order reversal from RIGHT JOIN optimizations
  • WHERE clause filter placement in execution pipeline

Permanent Solution:

• Update to SQLite ≥3.39.0 with the specific fix
• Review all RIGHT JOIN queries for:
  • WHERE clauses comparing columns from LEFT JOIN tables
  • Implicit NULL comparisons without IS TRUE/IS FALSE checks
• Consider replacing RIGHT JOIN with LEFT JOIN where possible

Preventive Measures:

• Enable strict NULL handling: PRAGMA defer_foreign_keys=ON;
• Use explicit IS [NOT] TRUE/FALSE in WHERE clauses involving OUTER JOINs
• Monitor query plans for automatic index usage on NULL-prone columns

This comprehensive approach addresses both immediate workarounds and long-term prevention of similar optimization conflicts between automatic indexes and RIGHT JOIN semantics.
