Unexpected Results in SQLite Window Function Due to IDENTITY Misuse

Issue Overview: Misinterpretation of IDENTITY Keyword in SQLite Schema Definition

The core issue revolves around the unexpected behavior observed when using the IDENTITY keyword in a SQLite table definition, specifically in conjunction with a primary key column. The user expected SQLite to either interpret IDENTITY as an auto-incrementing mechanism for the primary key or to throw an error if IDENTITY was not a valid keyword. However, SQLite silently accepted the IDENTITY keyword without error, leading to unexpected results in the output of a window function query.

The problem manifests in two scenarios:

1. When the IDENTITY keyword is used in the column definition (id integer IDENTITY primary key), SQLite does not treat the id column as an auto-incrementing primary key. Instead, it interprets IDENTITY as part of the column’s data type, resulting in the id column being populated with NULL values. This leads to incorrect results when using a window function (sum(HAB-DEB) over (order by id asc)) because the id column, which is used for ordering, contains NULL values.
2. When the IDENTITY keyword is removed or commented out (id integer /*IDENTITY*/ primary key), SQLite correctly interprets the id column as an auto-incrementing primary key, and the window function produces the expected results.

The confusion arises because SQLite does not support the IDENTITY keyword in the same way as other databases like MS SQL Server. In SQLite, the correct way to define an auto-incrementing primary key is to use INTEGER PRIMARY KEY or INTEGER PRIMARY KEY AUTOINCREMENT. The IDENTITY keyword is not recognized as a valid constraint or data type modifier, but SQLite does not raise an error when it encounters this keyword in certain positions within the column definition.

Possible Causes: SQLite’s Flexible Type Affinity and Silent Handling of Unknown Keywords

The root cause of this issue lies in SQLite’s flexible type affinity system and its handling of unknown or unsupported keywords. SQLite’s type system is more permissive compared to other databases, allowing for a wide range of type names and modifiers. When SQLite encounters a column definition like id integer IDENTITY primary key, it does the following:

1. Type Affinity Determination: SQLite parses the column definition and determines the type affinity based on the rules outlined in the SQLite documentation on datatypes. In this case, integer IDENTITY is interpreted as a single type name, and SQLite assigns the INTEGER affinity to the column.
2. Primary Key Constraint: The primary key constraint is recognized and applied to the column. However, since IDENTITY is not a valid constraint or modifier in SQLite, it is ignored.
3. Auto-Increment Behavior: SQLite does not automatically treat the id column as an auto-incrementing column because the IDENTITY keyword is not recognized. As a result, the id column is populated with NULL values when rows are inserted.

The silent handling of the IDENTITY keyword is due to SQLite’s design philosophy of being permissive and forgiving in its syntax. This can lead to confusion, especially for users coming from other databases where IDENTITY is a well-defined and supported keyword for auto-incrementing columns.

Troubleshooting Steps, Solutions & Fixes: Correcting the Schema and Understanding SQLite’s Behavior

To resolve this issue and ensure that the id column behaves as expected, follow these steps:

1. Correct the Column Definition: Replace the IDENTITY keyword with the appropriate SQLite syntax for defining an auto-incrementing primary key. There are two ways to do this:

   • Use INTEGER PRIMARY KEY: This will automatically make the id column an auto-incrementing primary key.
   • Use INTEGER PRIMARY KEY AUTOINCREMENT: This explicitly specifies that the id column should auto-increment. Note that AUTOINCREMENT is optional and is only necessary if you want to prevent the reuse of row IDs after rows are deleted.

   Example:

   CREATE TABLE CUENTAS22 (
       id INTEGER PRIMARY KEY,  -- or INTEGER PRIMARY KEY AUTOINCREMENT
       N_CUENT VARCHAR(6) NOT NULL,
       FECH DATE NOT NULL,
       N_DOC VARCHAR(6) NOT NULL,
       DESCR VARCHAR(29),
       DEB NUMERIC(15) NOT NULL DEFAULT 0,
       HAB NUMERIC(15) NOT NULL DEFAULT 0,
       SALD NUMERIC(15) NOT NULL DEFAULT 0,
       P BIT
   );


2. Verify the Column Behavior: After correcting the schema, verify that the id column is behaving as expected by inserting rows and checking the values assigned to the id column. The id column should now be populated with sequential integers, starting from 1.

   Example:

   INSERT INTO CUENTAS22(N_CUENT, FECH, N_DOC, DEB, HAB)
   VALUES
       ('0001', '2022-01-03', '88', 1, 0),
       ('0002', '2022-01-03', '89', 2, 0),
       ('0003', '2022-01-03', '90', 3, 0),
       ('0004', '2022-01-03', '91', 0, 10),
       ('0005', '2022-01-03', '92', 1, 20),
       ('0006', '2022-01-03', '93', 0, 30);

   SELECT * FROM CUENTAS22;


   The output should show the id column populated with sequential integers:

   1|0001|2022-01-03|88||1|0|0|
   2|0002|2022-01-03|89||2|0|0|
   3|0003|2022-01-03|90||3|0|0|
   4|0004|2022-01-03|91||0|10|0|
   5|0005|2022-01-03|92||1|20|0|
   6|0006|2022-01-03|93||0|30|0|


3. Re-run the Window Function Query: With the id column correctly populated, re-run the window function query to ensure that the results are as expected.

   Example:

   SELECT
       id,
       N_CUENT,
       FECH,
       N_DOC,
       DESCR,
       DEB,
       HAB,
       SALD,
       P,
       sum(HAB-DEB) OVER (ORDER BY id ASC) AS runsald
   FROM CUENTAS22;


   The output should now show the correct running balance (runsald) for each row:

   1|0001|2022-01-03|88||1|0|0||-1
   2|0002|2022-01-03|89||2|0|0||-3
   3|0003|2022-01-03|90||3|0|0||-6
   4|0004|2022-01-03|91||0|10|0||4
   5|0005|2022-01-03|92||1|20|0||23
   6|0006|2022-01-03|93||0|30|0||53


4. Understand SQLite’s Type Affinity and Syntax Rules: To avoid similar issues in the future, it is important to understand how SQLite handles type affinity and syntax. SQLite’s type system is designed to be flexible, but this flexibility can lead to unexpected behavior if you are not familiar with its rules. Always refer to the SQLite documentation on datatypes and autoincrement for guidance on defining columns and constraints.

5. Use Explicit Constraints and Modifiers: When defining columns, use explicit constraints and modifiers that are supported by SQLite. Avoid using keywords or syntax from other databases unless you are certain that they are supported by SQLite. If you are unsure, consult the SQLite documentation or test the schema in a controlled environment before deploying it to production.

By following these steps, you can ensure that your SQLite schema is correctly defined and that your queries produce the expected results. Understanding SQLite’s behavior and syntax rules is key to avoiding similar issues in the future.
