Query Plan Regression in SQLite 3.39+ Due to CTE Materialization Changes

Root Cause: CTE Materialization Strategy Alterations in SQLite 3.39+

Issue Overview

A complex analytical query involving multiple Common Table Expressions (CTEs) experienced a severe performance regression when executed in SQLite versions 3.39.0 through 3.40.1 compared to version 3.38.5. The query, which calculates a rolling least squares fit over time-series data stored in a summary table with ~337k rows, shifted from executing in seconds to hours after upgrading. The regression stemmed from changes to how SQLite’s query planner handles CTE materialization and index selection.

The query relies heavily on the summary_ix index (defined as CREATE UNIQUE INDEX summary_ix ON summary(country, date)) to efficiently filter rows by country and date ranges. In SQLite 3.38.5, the query plan utilized this index directly for range scans and joins. However, in versions 3.39.0 and later, the planner began favoring automatic covering indexes and introduced additional materialization steps for CTEs, bypassing the optimal use of summary_ix. This resulted in full table scans (SCAN summary) and inefficient temporary B-tree operations (USE TEMP B-TREE), drastically increasing execution time.

Key observations from the query plans:

1. 3.38.5 Plan:

   • Efficient use of summary_ix for SEARCH operations with country=? AND date>? predicates.
   • Minimal temporary B-tree usage (only for ORDER BY and GROUP BY in CTEs).
   • Direct joins between CTEs and base tables using indexed columns.

2. 3.40.1 Plan:

   • Proliferation of MATERIALIZE steps for CTEs (raw, init, src, vals, sums, mult).
   • Reliance on AUTOMATIC COVERING INDEX instead of summary_ix for critical date-range filters.
   • Increased use of temporary B-trees for intermediate results, slowing down large dataset processing.

The regression was traced to changes in SQLite’s cost model for materializing CTEs, introduced in version 3.39.0 alongside support for explicit MATERIALIZED/NOT MATERIALIZED hints. These changes inadvertently disabled query flattening optimizations for CTEs referenced multiple times, forcing unnecessary materialization and suboptimal index selection.

Critical Factors Behind the Regression

1. CTE Materialization Forced by Query Planner

   • In SQLite 3.39+, CTEs referenced more than once were implicitly treated as MATERIALIZED, preventing query flattening (integrating CTE logic into the main query). This led to redundant computations and loss of index-driven optimizations.
   • Example: The raw CTE (SELECT country, date, ... FROM summary) was materialized as a temporary table, stripping away the summary_ix index and forcing full scans.

2. Automatic Covering Index Misapplication

   • The planner’s preference for automatic covering indexes over explicit indexes (summary_ix) in materialized CTEs caused inefficient SEARCH operations. Automatic indexes lack the selectivity of summary_ix for country/date predicates, increasing I/O.

3. Temporary B-Tree Overhead

   • Materialized CTEs required temporary B-trees for sorting/grouping (USE TEMP B-TREE FOR GROUP BY), which scaled poorly with large datasets.

4. Cost Model Adjustments

   • A tuning parameter (rSetup) in SQLite’s cost calculation for materialized objects was adjusted, making the planner overly optimistic about the efficiency of automatic indexes for CTEs.

Comprehensive Troubleshooting and Resolution Strategies

Step 1: Validate Query Plan Changes

• Action: Compare EXPLAIN QUERY PLAN outputs across SQLite versions.
• Example:

  EXPLAIN QUERY PLAN
  WITH RECURSIVE ... [full query];


• Outcome: Identify shifts from SEARCH summary USING INDEX summary_ix to SCAN summary or AUTOMATIC COVERING INDEX.

Step 2: Apply Immediate Workarounds

1. Force Index Usage:
   Modify CTEs to explicitly reference summary_ix using INDEXED BY clauses.

   WITH raw AS (
     SELECT country, date, total_c AS total, delta_c_7d AS delta
     FROM summary INDEXED BY summary_ix
     WHERE ...
   )


   Caution: Overuse of INDEXED BY can destabilize future optimizations.

2. Rewrite CTEs as Subqueries:
   Replace CTEs with derived tables to encourage query flattening.

   SELECT ...
   FROM (
     SELECT country, date, ... FROM summary
     WHERE country=? AND date>?
   ) AS raw
   JOIN ...


   Benefit: Subqueries are more likely to be flattened, preserving index usage.

3. Use Temporary Tables:
   Materialize critical CTEs manually and index them.

   CREATE TEMP TABLE raw_temp AS
   SELECT country, date, ... FROM summary WHERE ...;
   CREATE INDEX tmp_raw_idx ON raw_temp(country, date);


   Trade-off: Adds complexity but guarantees index availability.

Step 3: Apply SQLite Source Code Patch

For versions 3.39.0–3.40.1, apply the patch provided in the discussion to adjust the rSetup cost heuristic:

--- src/where.c
+++ src/where.c
@@ -3590,17 +3590,17 @@
     ** of X is smaller for views and subqueries so that the query planner
     ** will be more aggressive about generating automatic indexes for
     ** those objects, since there is no opportunity to add schema
     ** indexes on subqueries and views. */
     pNew->rSetup = rLogSize + rSize;
     if( !IsView(pTab) && (pTab->tabFlags & TF_Ephemeral)==0 ){
      pNew->rSetup += 28;
     }else{
-     pNew->rSetup -= 10;
+     pNew->rSetup -= 21;
     }
     ApplyCostMultiplier(pNew->rSetup, pTab->costMult);
     if( pNew->rSetup<0 ) pNew->rSetup = 0;
     /* TUNING: Each index lookup yields 20 rows in the table. This
     ** is more than the usual guess of 10 rows, since we have no way
     ** of knowing how selective the index will ultimately be. It would
     ** not be unreasonable to make this value much larger. */
     pNew->nOut = 43; assert( 43==sqlite3LogEst(20) );

Effect: Restores the planner’s preference for existing indexes over automatic indexes in CTEs.

Step 4: Upgrade to SQLite 3.41+ with CTE Optimization Fixes

The root cause was resolved in SQLite trunk check-in 66f29c403d28630b, which:

• Re-enabled query flattening for CTEs referenced multiple times.
• Revised the heuristic for marking CTEs as materialized.
• Preserved index usage in nested CTE structures.

Verification Steps:

1. Test the query with a pre-release snapshot.
2. Confirm the query plan reverts to using summary_ix for SEARCH operations.
3. Validate execution time matches or exceeds 3.38.5 performance.

Step 5: Query-Specific Optimizations

1. Simplify the fit CTE:
   Reduce joins by pre-computing values in earlier CTEs.

   -- Original
   fit AS (
     SELECT inv.country, inv.date, a * xy + b * y, c * xy + d * y
     FROM inv
     JOIN mult ON mult.country = inv.country AND mult.date = inv.date
     JOIN sums ON sums.country = mult.country AND sums.date = mult.date
   )
   -- Optimized
   fit AS (
     SELECT inv.country, inv.date,
            (inv.a * sums.xy) + (inv.b * sums.y) AS a_coeff,
            (inv.c * sums.xy) + (inv.d * sums.y) AS b_coeff
     FROM sums, mult, inv
     WHERE sums.country = mult.country
       AND sums.date = mult.date
       AND mult.country = inv.country
       AND mult.date = inv.date
   )


   Result: Fewer joins reduce temporary B-tree usage.

2. Leverage Partial Indexes:
   Add filtered indexes for country/date ranges in the summary table.

   CREATE INDEX summary_ix_active ON summary(country, date)
   WHERE total_c > 0;


   Benefit: Accelerates the init CTE’s min(date)/max(date) calculation.

3. Normalize Floating-Point Operations:
   Use ROUND() or precision constraints to mitigate floating-point discrepancies between versions.

   SELECT ..., ROUND(nFin/nPrev - 1, 4) AS growth
   FROM ...


   Rationale: Prevents insignificant rounding differences from affecting business logic.

Step 6: Monitor and Profile Future Upgrades

1. Benchmark Suite:
   Create a performance test harness that runs the query against multiple SQLite versions.
2. Query Plan Regression Checks:
   Automate EXPLAIN QUERY PLAN comparisons during upgrades.
3. Profile with sqlite3_profile():
   Use SQLite’s profiling API to measure time spent in materialization vs. index scans.

Final Note: The regression highlights the delicate balance between query planner optimizations and CTE materialization strategies. Developers using complex CTEs in SQLite should:

• Prefer subqueries over CTEs where possible.
• Explicitly index temporary tables derived from CTEs.
• Monitor query plans during upgrades using EXPLAIN QUERY PLAN.
• Engage with SQLite’s prerelease builds to validate fixes before official releases.

By adhering to these practices, users can mitigate risks associated with query planner changes while leveraging SQLite’s continuous performance improvements.
