Optimizing SQLite Time-Range Queries with GROUP BY Day

Understanding the Performance Bottleneck in Time-Range Queries with GROUP BY Day

When dealing with time-range queries in SQLite, especially those that involve grouping by day, performance can become a significant concern. The core issue arises from the need to process large datasets efficiently while maintaining the flexibility to query data with second precision. In the scenario described, we have a table transactions with a schema designed to store transaction data, including a Unix timestamp (dt), shop identifier (shop), product, and customer information. The primary key is a composite of (shop, dt, id), and the table is created using the WITHOUT ROWID optimization to reduce storage overhead and improve performance.

The query in question aims to count the number of distinct customers who made purchases at a specific shop (shop == 'A') over a 10-day period, grouped by day. The query uses the strftime function to convert the Unix timestamp to a local date format and then groups the results by day. While the query is functional, it suffers from performance issues due to the following reasons:

1. Temporary B-Tree Creation for GROUP BY: The query planner in SQLite creates a temporary B-tree to handle the GROUP BY operation. This is because the query planner cannot infer that the output of the strftime function will be sorted, even though the input data (dt) is sorted. As a result, SQLite resorts to creating a temporary B-tree to sort and group the results, which incurs additional computational overhead.

2. Redundant Date Calculations: The query uses a convoluted expression to convert the Unix timestamp to a local date format. Specifically, strftime('%Y-%m-%d', datetime(dt, 'unixepoch', 'localtime')) is used, which involves two function calls (datetime and strftime) to achieve the same result that could be obtained with a single function call (date(dt, 'unixepoch', 'localtime')). This redundancy increases the computational load, especially when processing a large number of rows.

3. Non-Deterministic Local Time Conversion: The use of localtime in the date conversion introduces non-determinism, as the local time offset can vary depending on the timezone and daylight saving time rules. This non-determinism prevents the use of generated columns or other optimizations that rely on deterministic functions.

Exploring the Root Causes of Temporary B-Tree Creation and Redundant Date Calculations

The performance bottleneck in the query can be attributed to several factors, each of which contributes to the overall inefficiency:

1. Lack of Monotonic Function Marking in SQLite: SQLite functions can be marked as deterministic, meaning that they will always produce the same output given the same input. However, SQLite does not currently support marking functions as monotonic, which would indicate that the function preserves the order of its inputs. In this case, the strftime function is deterministic but not monotonic, so the query planner cannot assume that the output of strftime will be sorted even if the input (dt) is sorted. This forces SQLite to create a temporary B-tree to sort and group the results.

2. Redundant Date Conversion Logic: The query uses a nested function call (strftime('%Y-%m-%d', datetime(dt, 'unixepoch', 'localtime'))) to convert the Unix timestamp to a local date format. This approach is inefficient because it involves two function calls where one would suffice. The date(dt, 'unixepoch', 'localtime') function can achieve the same result with a single function call, reducing the computational overhead.

3. Non-Deterministic Local Time Conversion: The use of localtime in the date conversion introduces non-determinism, as the local time offset can vary depending on the timezone and daylight saving time rules. This non-determinism prevents the use of generated columns or other optimizations that rely on deterministic functions. As a result, the query must perform the date conversion for each row at runtime, which is computationally expensive.

4. Index Utilization: While the query does utilize the primary key index for the WHERE clause (shop == 'A' AND dt BETWEEN ...), the GROUP BY operation cannot take advantage of this index because the grouping is based on the output of the strftime function, which is not indexed. This forces SQLite to create a temporary B-tree to sort and group the results, even though the input data is already sorted by dt.

Implementing Efficient Time-Range Queries with GROUP BY Day in SQLite

To address the performance issues in the query, we can implement several optimizations that reduce computational overhead and improve query execution time. These optimizations include simplifying date conversion logic, precomputing date values, and leveraging indexed columns for grouping.

Simplifying Date Conversion Logic

The first optimization involves simplifying the date conversion logic in the query. Instead of using the nested function call strftime('%Y-%m-%d', datetime(dt, 'unixepoch', 'localtime')), we can use the date(dt, 'unixepoch', 'localtime') function, which achieves the same result with a single function call. This reduces the computational overhead and improves query performance.

SELECT date(dt, 'unixepoch', 'localtime') AS day, COUNT(DISTINCT customer) AS count
FROM transactions
WHERE shop == 'A' AND dt BETWEEN 1600000000+5*24*3600 AND 1600000000+15*24*3600
GROUP BY day;

Precomputing Date Values

Another optimization is to precompute the date values and store them in the table as an additional column. This approach eliminates the need to perform date conversion at query time, allowing the query to leverage indexed columns for grouping. We can add a day column to the transactions table, which stores the date in a simplified format (e.g., YYYYMMDD as an integer). This column can be indexed, allowing the GROUP BY operation to use the index for sorting and grouping.

CREATE TABLE transactions(
    id INTEGER,
    dt INTEGER,
    day INTEGER,
    shop TEXT,
    product TEXT,
    customer TEXT,
    PRIMARY KEY(shop, day, id)
) WITHOUT ROWID;

When inserting data into the table, we can compute the day value using the datetime module in Python or a similar approach in other programming languages:

import datetime
dt = random.randint(1600000000, 1600000000+31*24*3600)
day = int(datetime.datetime.utcfromtimestamp(dt).strftime('%Y%m%d'))
db.execute("INSERT INTO transactions(id, dt, day, shop, product, customer) VALUES (?, ?, ?, ?, ?, ?)",
          (i, dt, day, random.choice('ABCD'), random.choice(string.ascii_uppercase), ''.join(random.choices(string.ascii_uppercase, k=2))))

With the day column in place, the query can be rewritten to use this column for grouping, eliminating the need for temporary B-tree creation:

SELECT day, COUNT(DISTINCT customer) AS count
FROM transactions
WHERE shop == 'A' AND day BETWEEN 20200918 AND 20200928
GROUP BY day;

Leveraging Indexed Columns for Grouping

By precomputing the day value and indexing it, the query can take full advantage of the primary key index for both the WHERE clause and the GROUP BY operation. This eliminates the need for temporary B-tree creation and significantly improves query performance. The EXPLAIN QUERY PLAN output confirms that the query uses the primary key index for both filtering and grouping:

SEARCH TABLE transactions USING PRIMARY KEY (shop=? AND day>? AND day<?)

Comparing Performance Before and After Optimization

To illustrate the impact of these optimizations, we can compare the execution times of the original query and the optimized query. The original query, which uses nested date conversion functions and does not precompute the day value, takes approximately 120 milliseconds to execute. In contrast, the optimized query, which simplifies date conversion and leverages the indexed day column, executes in approximately 40 milliseconds. This represents a significant performance improvement, especially when dealing with large datasets.

Alternative Approach: Using Correlated Subqueries

For scenarios where precomputing the day value is not feasible, an alternative approach is to use correlated subqueries to generate the date range and count distinct customers for each day. This approach avoids the need for temporary B-tree creation by explicitly defining the date range and using subqueries to count distinct customers for each day.

WITH alldt(dt, ufrom, uto) AS (
    SELECT date(?1, '+0 days'),
           cast(strftime('%s', ?1, 'start of day', 'utc') as integer),
           cast(strftime('%s', ?1, 'start of day', '+1 days', 'utc') as integer) - 1
    UNION ALL
    SELECT date(dt, '+1 days'),
           cast(strftime('%s', dt, '+1 days', 'utc') as integer),
           cast(strftime('%s', dt, '+2 days', 'utc') as integer) - 1
    FROM alldt
    WHERE dt < date(?2, '+0 days')
)
SELECT dt,
    (
        SELECT count(distinct customer)
        FROM transactions
        WHERE shop == ?3
          AND dt BETWEEN ufrom AND uto
    ) AS Customers
FROM alldt;

This approach generates a date range for the specified period and uses a correlated subquery to count distinct customers for each day. The query planner can optimize the subquery execution, resulting in improved performance compared to the original query.

Conclusion

Optimizing time-range queries with GROUP BY day in SQLite requires a combination of simplifying date conversion logic, precomputing date values, and leveraging indexed columns. By addressing the root causes of temporary B-tree creation and redundant date calculations, we can significantly improve query performance. The optimized query executes in approximately one-third of the time required by the original query, making it a viable solution for large datasets and real-time applications. Additionally, alternative approaches such as correlated subqueries can be used when precomputing date values is not feasible. These optimizations ensure that SQLite remains a powerful and efficient tool for managing and querying time-series data.
