Foreign Key Constraint Failure When Inserting Related Entities with Auto-Generated Keys in EF Core 6.0 and SQLite

Entity Framework Core Key Generation Behavior with SQLite Foreign Key Dependencies

Issue Overview: Mismatched Key Assignment Timing Between Parent and Child Entities

The core issue arises when attempting to insert a parent entity (Class1) and multiple related child entities (Class2) within a single transaction using Entity Framework Core 6.0 with a SQLite database. The failure occurs specifically when the parent entity’s primary key (Class1.Id) is configured for auto-generation (ValueGeneratedOnAdd) but is not explicitly assigned before being referenced as a foreign key in child entities.

In the failing scenario, the parent Class1 instance is created without explicitly defining its Id property. The child Class2 entities are then linked to the parent by setting their Class1Id foreign key property to the value of c1.Id after the parent is added to the context but before calling SaveChanges(). This results in a foreign key constraint violation because the parent’s Id has not been generated or propagated to the child entities at the time of insertion.

The working scenario avoids this issue by manually assigning a GUID string to Class1.Id before creating the child entities, ensuring the foreign key values are valid when the child entities are added to the context. The discrepancy highlights a critical gap in understanding how EF Core handles key generation for non-integer primary keys in SQLite and the timing of entity graph resolution during transactions.

Key technical factors contributing to the issue include:

1. SQLite’s lack of native server-side key generation for non-integer columns: Unlike integer keys (e.g., INTEGER PRIMARY KEY AUTOINCREMENT), SQLite does not automatically generate values for string-based primary keys.
2. EF Core’s client-side key generation logic: For non-integer keys marked with ValueGeneratedOnAdd, EF Core relies on client-side value generators, which may not execute until SaveChanges() is called.
3. Transaction isolation and deferred key resolution: When operating within a transaction, EF Core may defer key generation until the entire change set is committed, leaving foreign key references unresolved during interim steps.

Possible Causes: Client-Side Key Generation Timing and SQLite Constraints

1. Misconfigured Client-Side Key Generation for String-Based Primary Keys
   EF Core’s ValueGeneratedOnAdd annotation signals that the database should generate the key value upon insertion. However, SQLite cannot generate string-based keys automatically. This creates an implicit expectation that the client (EF Core) will handle key generation. If no explicit client-side value generator (e.g., GUID generator) is configured, the Id property remains unassigned until SaveChanges() is invoked.

   In the failing code, Class1.Id is not assigned during object initialization. While EF Core might generate a temporary key for tracking entities in the change tracker, this temporary value is not persisted to the database or exposed via the entity’s Id property until after SaveChanges(). Consequently, child entities referencing c1.Id receive an invalid or null foreign key value.

2. Lack of Explicit Foreign Key Assignment Before Entity Attachment
   Child entities (Class2) are added to the context with an uninitialized Class1Id property. Although the code attempts to set Class1Id in a loop after adding the parent to the context, this assignment occurs too late in the entity attachment process. EF Core’s change tracker may have already captured the child entities’ state with null foreign keys, causing SQLite to reject the insertions due to the NOT NULL constraint on Class1Id.

3. Transaction Scope Delaying Key Propagation
   Transactions in SQLite enforce atomicity by deferring writes until the transaction is committed. When SaveChanges() is called within a transaction, EF Core may delay key generation until the transaction is committed, especially if batching is enabled. This delay prevents the parent’s Id from being available to child entities during the initial AddRange() operation.

4. Incorrect Mapping of Navigation Properties and Foreign Keys
   The fluent configuration for Class2 specifies DeleteBehavior.Restrict, which has no direct impact on insert operations but indicates potential misalignment between navigation properties and foreign key assignments. If the Class1 navigation property in Class2 is not properly synchronized with Class1Id, EF Core might fail to infer the correct foreign key value during relationship fix-up.

Troubleshooting Steps, Solutions & Fixes: Ensuring Key Availability and Correct Relationship Mapping

Step 1: Configure Client-Side Key Generation for String-Based Primary Keys
Since SQLite cannot generate string-based keys, explicitly define a client-side value generator for Class1.Id:

modelBuilder.Entity<Class1>()
    .Property(e => e.Id)
    .HasValueGenerator<GuidStringValueGenerator>()
    .ValueGeneratedOnAdd();

This configuration instructs EF Core to generate a new GUID string for Class1.Id when the entity is added to the context. The GuidStringValueGenerator is a custom class that extends ValueGenerator<string>:

public class GuidStringValueGenerator : ValueGenerator<string>
{
    public override string Next(EntityEntry entry) => Guid.NewGuid().ToString();
    public override bool GeneratesTemporaryValues => false;
}

With this setup, Class1.Id is populated immediately when the entity is instantiated, eliminating the need to manually assign Id before creating child entities.

Step 2: Assign Foreign Keys During Child Entity Initialization
Modify the child entity creation logic to set Class1Id directly during initialization, leveraging the now-available c1.Id:

var c1 = new Class1 { Name = "Abc" }; // Id is auto-generated by GuidStringValueGenerator
var c2s = new List<Class2>
{
    new Class2 { Name = "Efg", Class1Id = c1.Id },
    new Class2 { Name = "Deg", Class1Id = c1.Id },
    new Class2 { Name = "Xyz", Class1Id = c1.Id }
};

This ensures foreign keys are valid before the child entities are added to the context.

Step 3: Utilize Navigation Properties for Implicit Foreign Key Assignment
EF Core automatically synchronizes navigation properties with foreign key values when both ends of a relationship are properly configured. Modify the code to establish the relationship via the Class1 navigation property instead of manually setting Class1Id:

var c1 = new Class1 { Name = "Abc" };
var c2s = new List<Class2>
{
    new Class2 { Name = "Efg", Class1 = c1 },
    new Class2 { Name = "Deg", Class1 = c1 },
    new Class2 { Name = "Xyz", Class1 = c1 }
};

EF Core will populate Class1Id in each Class2 instance based on c1.Id during the relationship fix-up phase, which occurs before SaveChanges().

Step 4: Validate Transaction Handling and SaveChanges Order
Ensure the transaction is correctly scoped and that all entities are added to the context before invoking SaveChanges():

using var tr = _context.Database.BeginTransaction();
try
{
    _context.Add(c1);
    _context.AddRange(c2s);
    _context.SaveChanges(); // Generates keys and fixes up relationships
    tr.Commit();
}
catch
{
    tr.Rollback();
    throw;
}

By adding both the parent and child entities to the context before SaveChanges(), EF Core can resolve relationships and assign foreign keys in a single operation.

Step 5: Verify SQLite Foreign Key Enforcement Settings
SQLite allows foreign key constraints to be disabled by default. Ensure foreign key enforcement is enabled in the connection string:

Data Source=mydatabase.db;Foreign Keys=True;

Additionally, confirm that the DbContext is configured to enforce foreign keys:

modelBuilder.Entity<Class2>()
    .HasOne(e => e.Class1)
    .WithMany(e => e.Class2s)
    .HasForeignKey(e => e.Class1Id)
    .OnDelete(DeleteBehavior.Restrict)
    .IsRequired();

Step 6: Inspect Generated SQL Statements for Key Insertion Order
Use EF Core’s logging capabilities to capture the SQL statements executed during SaveChanges(). Verify that the Class1 insert occurs before the Class2 inserts and that the generated Id is correctly referenced in the child records:

optionsBuilder.UseSqlite("Data Source=mydatabase.db")
    .LogTo(Console.WriteLine, LogLevel.Information);

The logged SQL should resemble:

-- INSERT INTO Class1 (Id, Name) VALUES ('generated-guid', 'Abc');
-- INSERT INTO Class2 (Id, Name, Class1Id) VALUES ('generated-guid', 'Efg', 'generated-guid');

Step 7: Consider Using Integer Keys with Auto-Increment for Simplified Key Management
If string-based keys are not required, switch to integer keys with SQLite’s native auto-increment functionality:

public class Class1
{
    [Key]
    [DatabaseGenerated(DatabaseGeneratedOption.Identity)]
    public virtual int Id { get; set; }
    // Other properties
}

This leverages SQLite’s built-in key generation, ensuring Id is available immediately after SaveChanges() without client-side intervention.

Step 8: Implement Explicit Value Generation for Composite Keys or Custom Scenarios
For complex key generation requirements (e.g., formatted strings), use DbContext lifecycle events to populate keys before insertion:

_context.SavingChanges += (sender, args) =>
{
    foreach (var entry in _context.ChangeTracker.Entries<Class1>())
    {
        if (entry.State == EntityState.Added)
        {
            entry.Entity.Id = GenerateCustomId();
        }
    }
};

Final Solution Summary
The foreign key constraint failure stems from unresolved parent key references during child entity insertion. By configuring client-side key generation for string-based primary keys, assigning foreign keys during child initialization, and leveraging EF Core’s relationship fix-up mechanics, the issue is resolved. Transactions and SQLite’s key generation limitations necessitate careful coordination between entity attachment order and key availability.
