Breadth-First Graph Traversal in SQLite: Performance and Optimization

Recursive CTE Performance Issues in Breadth-First Graph Traversal

When performing a breadth-first traversal of a graph stored in an SQLite database using a recursive Common Table Expression (CTE), a common issue arises: the traversal becomes inefficient for larger graphs due to repeated visits to the same nodes. This inefficiency stems from the nature of recursive CTEs in SQLite, which do not inherently support tracking visited nodes within the recursion itself. As a result, nodes with multiple incoming edges are revisited multiple times, leading to redundant computations and significantly slower query execution.

For example, consider a graph represented by the following edges:

create table edges(fromNode integer, toNode integer);
insert into edges(fromNode, toNode) values
 (1, 2),
 (1, 3),
 (2, 4),
 (3, 4),
 (5, 6);

A typical recursive CTE for breadth-first traversal might look like this:

with recursive
 bfs_tree(id, parent, distance) as (
 select 1, NULL, 0
 union all
 select edges.toNode, bfs_tree.id, bfs_tree.distance + 1
 from edges, bfs_tree
 where edges.fromNode = bfs_tree.id
 order by 3
 )
select id, parent, min(distance) from bfs_tree
group by id;

While this query works for small graphs, it becomes inefficient for larger graphs because nodes like 4 in the example are visited multiple times via different paths (e.g., 1 → 2 → 4 and 1 → 3 → 4). This redundancy is a direct consequence of SQLite’s recursive CTE implementation, which processes each row in isolation during recursion and does not maintain a global state of visited nodes.

Limitations of SQLite Recursive CTEs in Tracking Visited Nodes

The core issue lies in the design of SQLite’s recursive CTEs. When a recursive CTE is executed, each recursive step processes a single row from the previous step. This means that the recursive query does not have access to the complete set of rows generated so far, making it impossible to track visited nodes globally within the CTE itself. As a result, nodes with multiple incoming edges are revisited, leading to exponential growth in the number of rows processed and a corresponding degradation in performance.

For instance, in the following directed acyclic graph (DAG):

1
|\
2 3
|/
4
|\
5 6
|/
7

The recursive CTE will generate multiple paths to nodes like 4, 5, 6, and 7, even though these nodes only need to be visited once for a breadth-first traversal. This behavior is particularly problematic in graphs with many overlapping paths, such as social networks, dependency graphs, or organizational hierarchies.

To illustrate, consider the following query:

with recursive
 bfs_tree(id, visited, distance) as (
 select 1, '/' || 1 || '/', 0
 union all
 select toNode, visited || toNode || '/', distance + 1
 from edges, bfs_tree
 where fromNode = id and instr(visited, '/' || toNode || '/') == 0
 order by 3 asc
 )
select * from bfs_tree;

This query attempts to track visited nodes using a visited column that stores the path taken to reach each node. While this approach prevents cycles, it does not eliminate redundant visits to nodes that can be reached via multiple paths. For example, node 4 is visited twice (via 1 → 2 → 4 and 1 → 3 → 4), and node 7 is visited four times (via 1 → 2 → 4 → 5 → 7, 1 → 2 → 4 → 6 → 7, 1 → 3 → 4 → 5 → 7, and 1 → 3 → 4 → 6 → 7).

Optimizing Breadth-First Traversal with Virtual Tables and Custom Extensions

Given the limitations of recursive CTEs in SQLite, one effective solution is to implement a custom virtual table extension that performs breadth-first traversal while maintaining a global set of visited nodes. This approach leverages SQLite’s extensibility to introduce new functionality that is not natively supported by its recursive CTE implementation.

A virtual table extension for breadth-first traversal can use an in-memory data structure, such as an AVL tree or a hash table, to track visited nodes efficiently. By maintaining this global state, the extension ensures that each node is visited only once, regardless of the number of paths leading to it. This significantly reduces the computational overhead and improves query performance for large graphs.

For example, the sqlite3-bfsvtab-ext extension implements a virtual table that performs breadth-first traversal using an AVL tree to track visited nodes. The extension supports integer node IDs and can be used as follows:

CREATE VIRTUAL TABLE bfs USING bfsvtab(
    tablename='edges',
    fromcolumn='fromNode',
    tocolumn='toNode'
);

SELECT * FROM bfs WHERE start = 1;

This query performs a breadth-first traversal starting from node 1 and returns the results without revisiting any nodes. The extension handles the traversal logic internally, ensuring optimal performance even for large graphs.

Key Features of the Virtual Table Extension

• Global Visited Node Tracking: The extension maintains a global set of visited nodes using an AVL tree, ensuring that each node is processed only once.
• Efficient Memory Usage: The AVL tree provides efficient lookup and insertion operations, minimizing memory overhead.
• Customizable Traversal: The extension allows filtering and ordering of node neighbors, enabling more complex traversal scenarios.
• Scalability: By avoiding redundant computations, the extension scales well to large graphs with millions of nodes and edges.

Example Use Case

Consider a social network graph where each node represents a user, and edges represent friendships. Performing a breadth-first traversal to find all friends within a certain distance from a given user is a common operation. Using the virtual table extension, this can be achieved efficiently:

CREATE VIRTUAL TABLE social_bfs USING bfsvtab(
    tablename='friendships',
    fromcolumn='user_id',
    tocolumn='friend_id'
);

SELECT * FROM social_bfs WHERE start = 123 AND distance <= 3;

This query returns all users within three degrees of separation from user 123, ensuring that each user is visited only once.

Future Enhancements

While the current implementation of the virtual table extension supports basic breadth-first traversal, there are several areas for improvement:

• Support for Non-Integer Node IDs: Extending the extension to handle string or composite keys would make it more versatile.
• Filtering and Ordering: Adding support for filtering and ordering node neighbors based on additional criteria would enable more complex queries.
• Bidirectional Traversal: Implementing bidirectional traversal would allow the extension to handle undirected graphs more efficiently.

By addressing these enhancements, the virtual table extension can become a powerful tool for graph traversal in SQLite, offering performance and flexibility that surpasses native recursive CTEs.

Conclusion

Breadth-first graph traversal in SQLite presents unique challenges due to the limitations of recursive CTEs in tracking visited nodes. While recursive CTEs are a powerful tool for many tasks, their design makes them inefficient for large graphs with overlapping paths. By leveraging SQLite’s extensibility and implementing a custom virtual table extension, it is possible to overcome these limitations and achieve efficient, scalable breadth-first traversal. The sqlite3-bfsvtab-ext extension demonstrates how this can be done, providing a robust solution for graph traversal in SQLite.
